288 Core G652D Direct Buried Cable GYDTS Ribbon Optical Fiber Cable
Place of Origin: China
Brand Name: KNOFC or OEM
Certification: ISO9001/CE
Model Number: GYDTS 288 core
Minimum Order Quantity: 1km
Price: Negotiable
Packaging Details: Wooden drum
Delivery Time: 8-10 working days
Supply Ability: 100000M/Week
详情介绍
Fiber Type: G652D Or As Your Request Fiber Count: 2-576core
Outer Sheath Of Material: HDPE Strength Member: Steel Wire
Armored Layer: Corrugated Steel Tape Application: Duct / Aerial / Direct Duried
Outer Sheath Material: HDPE Life Expectancy: More Than 30 Years
Operating Temperature: -40°C To+70°C
High Light: 288 Core G652D Ribbon Optical Fiber Cable, GYDTS Ribbon Optical Fiber Cable, GYDTS 288 Core Fiber Optic Cable

GYDTS Ribbon optical fiber cable 288 core G652D duct direct buried



Description:

The structure of the GYDTA cable is to insert 4, 6, 8, 12, 24 fiber ribbon into a loose tube made of a high modulus material, and the loose tube is filled with a waterproof compound. The center of the core is a metal reinforced core. For some cores, a layer of polyethylene (PE) is required to be extruded outside the metal reinforced core. The loose tube and the filling rope are twisted around the central reinforcing core into a compact and round core, and the gap in the core is filled with a water-blocking filler. The plastic coated aluminum strip (APL) is longitudinally wrapped and extruded into a polyethylene sheath to form a cable.



Characteristics:

1. Good mechanical and temperature performance.
2. High strength loose tube that is hydrolysis resistant.
3. Special tube filling compound ensure a critical protection of fiber.
4. Specially designed compact structure is good at preventing loose tubes from shrinking.
5. HDPE sheath protects cable from ultraviolet radiation.
6. The following measures are taken to ensure the cable watertight:

           a. Steel wire used as the central strength member
           b. Loose tube filling compound
           c. 100% cable core filling
           d. APL moisture barrier



Feature:

  • Steel wire used as the central strength member
  • Loose tube filling compound
  • 100% cable core filling
  • PSP enhancing moisture-proof

Application:

  1. Adopted to outdoor distribution
  2. Suitable for aerial, pipeline and direct buried laying method
  3. Long distance and local area network communication

Cable Mechanical characteristic:

Cable typeDiameter (mm)Weight (kg/km)Tensile strength
Long/short term (N)
Crush Resistance Long/Short Term(N/100mm)Bending radius
Dynamic/static (mm)
Storage temperature    ( ℃ )
GYDTS-2~6010.0110600/1500300/100020D/10D-40~+70
GYDTS-62~7210.5120
GYDTS-74~9612.0145
GYDTS-98~12014.0160
GYDTS-122~14416.7268
GYDTS-146~28817.7293
GYDTS-300~36018.8330
GYDTS-372-43221.5417
GYDTS-57623.1479

288 Core G652D Direct Buried Cable GYDTS Ribbon Optical Fiber Cable 0
