ODF 1U Optical Fiber Terminal Box Rack Mount Patch Panel
Place of Origin: China
Brand Name: KNOFC or OEM
Certification: CE/ISO9001
Model Number: Fiber Optic Patch Panel 24 Ports 1U
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: carton
Supply Ability: 50000pcs/month
详情介绍
Material: Cold Roll Steel Sheet Color: Black
Connector: SC LC FC ST Application: FTTX Network
Port: 12/24/48/96/144 External Size: 1U,2U,3U,4U
High Light: ODF 1U Optical Fiber Terminal Box, 1U Rack Mount Patch Panel, ODF Rack Mount Patch Panel

ODF 1U Optical Fiber Terminal Box Patch Panel Rack Mount type



Description:

Fiber optic patch panel ,Fiber optic distribution frame, fiber optic distribution Box, ODF ,fiber optic Indoor wall box, Fiber optic Outdoor wall box,Optical Terminal Box (OTB) is mainly used for connecting the indoor/outdoor optical cables, optical patch cords and optical pigtails.



Features:

1. Made of cold-rolling steel, static spreading-plastic, small dimension and exquisite and easy for operation
2. The box are Rack Mounted, which is convenient to install and dismantle
3. The splice tray could be piled one upon another, flexible to turn
4. The curve radius of the coiled spear fibers should be guaranteed to be over 37.5mm in the splice tray
5. The box is of unique structure, reasonable layout, and has adequate room for operation; Adjustable clamp seal ring and reinforce configuration, which could adjust different sizes of cables flexibly to make sure the cables are clamp tightly
6. The indoor type is of excellent seal performance, which could prevent water from entering effectively



Technique Performance:

1. External size 480x250x1U, 2U,
2. Fiber capacity from 12 cores to 48 cores
3. Insertion loss: <0.3dB
4. Return loss: PC< 40 dB, UPC<50dB, APC< 60dB
5. Winding radius ≥40mm
6. Working temperature -25°C~+45°C
7. Atmosphere pressure 70~106Kpa
8. Insulated Resistance 2×10MΩ/500V(DC)W
9. Voltage- resistance:Under the effect of 3kv/DC/1min, non-puncture, and no arc-over.



Specification:

Environmental temperature:-25 - 55°C
Relative humidity:<85%(when the temperature is below 30°C)
Atmosphere pressure:70~106Kpa
Insulating resistance:>2×104 MΩ/500VDC
Voltage-resistance strength:Under the effect of 15kv/DC/1min, non-puncture, and no arc-over.



Application:

1. Widely used in FTTH access network
2. Telecommunication networks
3. CATV networks, LAN Network
4. Data communications networks
5. Local area networks
6. Active device termination



ODF 1U Optical Fiber Terminal Box Rack Mount Patch Panel 0
