24 Core Gpon MPO MTP LC FTTH Fiber Optic Patch Cord Panel

Place of Origin: China
Brand Name: KNOFC or OEM
Certification: CE/ISO9001
Model Number: MPO-MPO 24F OM3
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: bag or customized

我要询价

详情介绍

Fiber Count:	24 Cores	Fiber Type:	SM/OM1/OM2/OM3/OM4/OM5
Quality:	100% Pass Test	Application:	FTTX
Jacket Material:	LSZH, PVC, OFNR, OFNP	Fiber Brand:	YOFC/ Fiber Home/ Corning/ KNOFC
Cable Length:	1M Or Customized	Operating Temperature:	-30°C To+60°C
High Light:	24 Core FTTH Patch Cord Panel, 24 Core Fiber Optic Patch Panel, MPO MTP FTTH Patch Cord Panel

MPO/MTP LC FTTH Fiber Optic Patch Cord Cable Panel 24 Cores Gpon

Description:

MPO/MTP patch cord are designed to high density multi fibers solutions,fit for different installation environment and easy to in-stall between the trunk line,data centers and buildings.Our patch cord are 100% factory tested and can meet your special requirements.All the MPO/MTP connects comply with Telcordia GR-1435-Core Compliant.

Features:

High performance in IL&RL 100% pre-terminated tested.
Supports 40G and 100G network applications.
Jacket material: LSZH, OFNR, OFNP available.
Jacket color: Aqua,Yellow or customize.
Supports up to 4F,8F,12F, 24F, 48F, 72F, 96F, 144F, customized products are available.

Application:

Active dvice termination
Telecommunication networks
Metro
Local Area Networks(LANs)
Data Processing networks
Test Equipment
Premise installations
Wide Area Networks(WANs)

Connector Requirements:

Performance level

Standard

Elite

Connector	Mode	Endface	IL(max)(dB)	RL(max)(dB)	IL(max)(dB)	RL(max)(dB)
MPO/MTP	SM	PC	≤0.75	≥45	≤0.35	≥50
MPO/MTP	MM	PC	≤0.70	≥25	≤0.35	≥25
