Distribution Tight Buffer 12 Core Multimode Fiber Optic Cable

Place of Origin: China
Brand Name: KNOFC
Certification: CE/ISO9001
Model Number: GJPFJV
Minimum Order Quantity: 1km
Price: Negotiable
Packaging Details: wooden drum
Delivery Time: 8-10 working days
Supply Ability: 200km/week

我要询价

详情介绍

Fiber Type:	OM2 50/125	Fiber Count:	2-24 Core
Jacket Material:	LSZH/PVC	Application:	Indoor Cabling And Distribution
Fiber Brand:	YOFC / Fiberhome / Corning / KNOFC	Life Expectancy:	More Than 30 Years
Operating Temperature:	-40°C To+70°C
High Light:	12 Core Multimode Fiber Optic Cable, OM2 50/125 Tight Buffer Fiber Optic Cable, 12 Core Distribution Fiber Optic Cable

Indoor Communication Cable 12 core Multimode fiber cable distribution tight buffer Fiber

Description:

GJPFJV Multi-core round tight buffered distribution indoor fiber optic cable with good mechanical and environmental characteristics. Flame retardant characteristic meet the rquirements of relevant standards. The mechanical and physical characteristics of the outer jacket meet the requirement of relevant standards. Soft, flexible and easy to do stripping, splicing and cabling.

Features:

Flexible, flame-retardant & color coded outer jacket.
Non-unitized designs provide space savings and cost advantages.
Work as pigtails and patch cords.
Optical communication cables for inside plant installations.
Sitable for indoor use, communication equipment.

Application:

Indoor cabling and distribution.
Interconnection of fiber optic equipments, especially ODF.
Used in patch cords and pigtails

Optical Fiber Characteristic:

		G.652.D	G.655	50/125μm	62.5/125μm
Attenuation	@850nm			≤3.0 dB/km	≤3.0 dB/km
	@1300nm			≤1.0 dB/km	≤1.0 dB/km
	@1310nm	≤0.36 dB/km	≤0.40 dB/km
	@1550nm	≤0.22 dB/km	≤0.23dB/km
Bandwidth	@850nm			≥500 MHz·km	≥200 MHz·km
Bandwidth	@1300nm			≥1000 MHz·km	≥600 MHz·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelengthλcc		≤1260nm	≤1480nm

Technical parameters:

Cable type	Diameter(mm)	Weight (kg/km)	Tensile strength Long/short term (N)	Bending radius Dynamic/static (mm)	Storage temperature ( ℃ )
GJPFJV-4C	4.8	16.2	1000/3000	20D/10D	-40~+70
GJPFJV-6C	5.2	20.0	1000/3000	20D/10D	-40~+70
GJPFJV-8C	6.2	26.0	1000/3000	20D/10D	-40~+70
GJPFJV-12C	6.8	31.5	1000/3000	20D/10D	-40~+70
