Fiber Optic Pigtail
Current location:Home   >>  Products   >>  Fiber Optic Jumper   >>  Fiber Optic Pigtail
LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail
Place of Origin: China
Brand Name: KNOFC or OEM
Certification: CE/ISO9001
Model Number:Pigtail LC/UPC OM3 12C
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Plastic bag
Supply Ability: 20000pcs/Week
Fiber Type: Single Mode 9/125 Connector Type: LC/UPC 12C
Length: 1M Or Customized Cable Color: White Or Yellow
Cable Diameter: 0.9mm Insertion Loss: ≤0.3dB
Operating Temperature: -20°C To+50°C
High Light: OM3 Fiber Optic Pigtail, 1.5M Fiber Optic Pigtail, 50/12 OM3 Fiber Pigtail

OM3 Fiber Optic Pigtail LC 12 Core 50/12 Multimode 1M 1.5M



The optical Fiber Connectors (Commonly we call Patch Cords) is a length of optical cable with connectors fixed on one ends to realize the optical path active connection. Pigtail is a length fiber cable with only one connector fixed on one end. According to the transmission medium, it divides Single Mode and Multi Mode; according to the connector structure type, it divides FC, SC, ST, MU, D4, E2000,LC etc.; according to the polished ceramic end-face, it divides PC, UPC and APC.



  • Good durability.
  • Good exchangeability.
  • High temperature stability.
  • Low insertion loss and back reflection loss.
  • Superior Quality Standard PC/UPC/APC Polishin.



  • FTTH, LAN, Test equipment, Military industry.
  • Outside plant.
  • Premise networks.
  • Aerial distribution.
  • Measuring equipments.
  • Fiber optic communication system.
  • Optical active component and equipment.


 Parameter Unit Mode Type PC UPC APC
 Insertion Loss dB SM ≤0.3 ≤0.3 ≤0.3
 Insertion Loss dB MM ≤0.3 ≤0.3 -----
 Return Loss dB SM ≥50 ≥50 ≥60
 Return Loss dB MM ≥35 ≥35 -----
 Fiber cable Material PVC, LSZH
 Fiber cable Diameter 0.9mm, 2.0mm, 3.0mm
 Connector type SC, LC. ST. FC
 Repeatability dB Additional loss<0.1db,return loss< 5 dB
 Interchangeability dB Additional loss<0.1db,return loss< 5 dB
 Connection times times >1000
 Operating Temperature ℃ -20℃- +70℃
 Storage Temperature ℃ -20℃- +70℃


LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail 0

LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail 1

LC 12 Core 50/12 Multimode 1M 1.5M OM3 Fiber Optic Pigtail 2
